Downloads
This page provides downloadable documentation including technical information, setup and installation guides, cartridge alignment templates, recommended geometry specifications, and technical drawings. Files are available in PDF format. We recommend reviewing the full installation guide prior to setup to ensure correct mounting and optimal performance. Additional resources and documentation will be posted here as they become available.
Written for AXPONA 2026, this white paper describes the engineering principles behind the Unified Theory UA-101 precision tonearm, protected by US Patent 12,334,120 B2. Key innovations include the patented single-filament azimuth control system enabling real-time adjustment during playback, a mechanically stabilized neutral-balance unipivot, multi-level vibration management from headshell to pivot, and a six-axis headshell providing full cartridge alignment.
This is a custom alignment protractor for the Unified Theory UA-101 tonearm, specifying IEC-standard geometry: 220mm pivot-to-spindle distance, 15.75mm overhang, 235.75mm effective length, and 22.05° offset angle, with inner and outer null radii at 63mm and 114mm. An accompanying tracking distortion chart plots percentage distortion across groove radii from 50–150mm.
